접점 입력 - 시리얼 통신 본체 유닛
접점 입력 - 시리얼 통신 본체 유닛 WD PRO 송신기 및 LED 유닛을 추가하여 시리얼 데이터 습득 및 접점 입력 정보, 세부적인 작동 정보를 가시화할 수 있습니다.
- 무선 제품
- 실내 (똑바로)
WD PRO 용 송신기 WDT-6LR-Z2-PRO에 취부 가능합니다.
- 바코드 리더기를 부착하여 직원 세부 데이터를 관리하여 제품 품질 조절이 가능한 시리얼 통신 인터페이스가 특징입니다. 전체 시리얼 데이터는 60 바이트까지 습득 가능합니다.
- 외부 접점 입력 정보 (8점)을 통해 최대 255종의 정보를 취득 가능합니다. NPN/PNP/릴레이 접점 방식을 지원하며 2진수, 10진수, 16진수로 출력 가능합니다.
- 양방향 무선 통신 시스템을 지원하여 호스트 PC에서 시그널 타워를 원격 제어 가능합니다.
- WDS-WIN01(ver. 1.03 이상)를 통하여 CSV 출력이 가능해 더욱 쉽게 수치 계산 및 차트를 작성할 수 있습니다.
|Rated Voltage||24V DC|
|External Contact Input||Signal tower inputs (red, yellow, green, blue, white, buzzer); 8 external contact inputs; 1 reset input; serial communication input|
